| 기본사양 |
CPU & Chipset |
Intel®Celeron® Quad Core Jasper Lake |
| Memory |
DDR4 2GB ↑ |
| Storage |
2.5", SATA-III SSD 64GB ↑, Dual-mSATA(RAID) |
| Display |
15", 1024 X 768, 24Bit, Luminance : 300 cd/㎡, Backlight : LED |
| Dual Display port |
1EA HDMI, Intel® UHD Graphics |
| LAN |
1EA (Realtek Gigabit LAN) |
| Serial |
5EA (DSUB-9p x 2EA / RJ-45 x 3EA) |
| USB |
4EA(I/O)(USB3.0&2.0), 2EA (Rear) (USB 2.0) |
| USB |
4EA(I/O)(USB3.0&2.0), 2EA (Rear) (USB 2.0) |
| Audio |
Line-Out |
| Speaker |
1 EA (1W) |
| Cooler & FAN |
Fanless |
| Cash Drawer |
1 EA(RJ-11, 24V/12V) |
| Power Adaptor |
60[W] Adaptor, Input AC 100~240V/50~60HZ, DC 24V/2.5A |
| Dimension(mm) |
384(W) x 347(H) x 225(D) (Normal Angle, With Stand) |
| Weight |
4.8kg |
| OS supported |
Microsoft Windows 10 IoT / Linux |
| OS |
Microsoft Windows 10 IoT 64bit |
| Storage |
2.5", SATA-III HDD 500GB ↑ |
